Products specifications

Categories Resistors
Manufacturer Linear Technology
Series LT5400
Packaging Tube
Circuit Type Isolated
Resistance (Ohms) 1k
Tolerance ±7.5%
Number of Resistors 4
Number of Pins 8
Power Per Element 800mW
Temperature Coefficient ±25ppm/°C
Operating Temperature Range 0°C ~ 70°C
Applications Voltage Divider (TCR Matched)
Mounting SMD
Package 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
Manufacturer Package 8-MSOP-EP
Dimension 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Maximum) 0.043" (1.10mm)
Win Source Part Number 781458-LT5400ACMS8E-4#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LT5400
Introduction Date April 25, 2011
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LT5400ACMS8E-4#PBF CAD Model

Description

The LT5400ACMS8E-4#PBF is a high-precision, quad resistor network crafted by Linear Technology, which now operates as part of Analog Devices, Inc. This component is designed to offer excellent matching characteristics, making it an ideal choice for critical signal conditioning applications in measurement and control systems.

Key Features

  • Precision Matching: The resistors in the LT5400ACMS8E-4#PBF are matched to within ±0.01% of each other, ensuring high accuracy in applications requiring matched resistive elements.
  • Temperature Coefficient: It boasts an excellent temperature coefficient of ±1ppm/°C, which guarantees stability over a wide temperature range.
  • Ratio Stability: The ratio drift is specified to be no more than 5 ppm/°C, ensuring that the resistor ratios remain stable with temperature changes.
  • Packaging: The device comes in a compact MSOP-8 package, which is suitable for space-constrained applications without compromising performance.
  • Operating Temperature Range: It can reliably operate across an industrial temperature range from -40°C to +125°C.

Applications

The LT5400ACMS8E-4#PBF is versatile and can be utilized in various applications, including precision voltage dividers, bridge circuits, and differential amplifier input scaling. Its high precision and stability make it particularly suitable for:

  • Data acquisition systems
  • Test and measurement equipment
  • Automotive sensors and controls
  • Industrial instrumentation
  • Medical equipment

Product Quality and Reliability

Linear Technology is renowned for its commitment to product quality and reliability. The LT5400ACMS8E-4#PBF is no exception, and it is designed to meet stringent requirements, ensuring long-term performance and consistency in demanding environments.

Conclusion

For precision applications that require high-accuracy resistor matching, the LT5400ACMS8E-4#PBF from Linear Technology stands out as a reliable and efficient solution. Its superior temperature performance and stable ratio characteristics make it a go-to choice for engineers and designers seeking to optimize their signal conditioning circuits for performance and precision.
