Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Linear Technology
Packaging Reel package
Voltage - Clamping 27V Adj
Technology External Switch
Number of Circuits 1
Applications Automotive
Mounting SMD
Package 12-WFDFN Exposed Pad
Manufacturer Package 12-DFN (4x3)
Voltage - Working 4 ~ 80V
Win Source Part Number 781433-LT4356IDE-2#TRPBF
Popularity Medium
Supply and Demand Status Limited
Family Name LT4356-2
Introduction Date January 20, 2009
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LT4356IDE-2#TRPBF CAD Model

Description

The LT4356IDE-2#TRPBF is a robust surge stopper device designed to protect sensitive electronic circuits from high voltage transients and surges. Manufactured by Linear Technology, a leader in high-performance analog integrated circuits, this component ensures reliable operation in environments prone to voltage spikes and surges, such as industrial, automotive, and telecommunications applications.

Key Features

  • Overvoltage Protection: The LT4356IDE-2#TRPBF effectively clamps transient overvoltages to a safe level without interrupting the supply, safeguarding downstream components from damage.
  • Wide Operating Voltage Range: This device supports a wide input voltage range, accommodating various application requirements and ensuring versatility across different platforms.
  • Adjustable Output Clamp Voltage: Users can set the desired clamp voltage level to meet specific circuit protection needs, providing tailored protection for each unique application.
  • Low Quiescent Current: The low current draw in operation makes this surge stopper an energy-efficient choice, which is particularly beneficial in battery-powered or energy-conscious systems.
  • Reverse Input Protection: It offers protection against reverse input voltages, which can accidentally occur in complex wiring environments, further ensuring the resilience of the protected system.

Applications

The LT4356IDE-2#TRPBF is suited for a variety of applications where voltage spikes and surges can be detrimental to electronic equipment, including:

  • Automotive electronics
  • Industrial control systems
  • Telecommunication infrastructure
  • Power supplies
  • Avionics and marine systems

Product Specifications

The LT4356IDE-2#TRPBF comes in a 12-lead plastic DFN package, characterized by its compact size and excellent thermal performance. It is designed for surface mount technology (SMT), which allows for efficient assembly and space-saving PCB design. The part number suffix 'TRPBF' indicates that the device is provided in tape and reel packaging, suitable for automated pick-and-place manufacturing processes, and is specified as lead-free (Pb-free), adhering to RoHS compliance standards.

With its combination of protection features, wide voltage range, and energy-efficient operation, the LT4356IDE-2#TRPBF surge stopper is an ideal solution for protecting sensitive electronic systems from voltage-related stress and damage.
