Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Hot Swap Controller
Number of Channels 1
Applications General Purpose
Features Auto Retry
Programmable Features Current Limit, Fault Timeout, OVP, Slew Rate, UVLO
Supply Voltage - Operating 9 V to 80 V
Temperature Range - Operating 0°C to 70°C
Operating Supply Current 2mA
Mounting SMD (SMT)
Case / Package 8-SOIC
Feature Pins FB, ON, PWRGD, TIMER
Win Source Part Number 020294-LT1641-2CS8#TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT1641-2CS8#TRPBF CAD Model

Description

LT1641-2CS8#TRPBF - Hot Swap Controller from Linear Technology

The LT1641-2CS8#TRPBF is a sophisticated hot swap controller designed by Linear Technology, now part of Analog Devices, engineered to enhance the safety and efficiency of board level power supply management. This innovative component allows users to insert or remove boards from live backplanes or other powered systems without causing glitches or disruptions, ensuring a seamless and reliable operation.

Key Features:

  • Integrated Fault Protection: The device incorporates overcurrent and overvoltage protection, ensuring the safety of the electronic system by preventing damage due to unexpected power surges or short circuits.
  • Adjustable Current Limit: Designers can set the current limit threshold according to their specific requirements, providing flexibility and control over the power management of the system.
  • High Voltage Operation: With an operating range up to 80V, the LT1641-2CS8#TRPBF is suitable for managing power in a wide variety of applications, from industrial to telecommunications systems.
  • Gate Drive for External N-Channel MOSFET: The controller efficiently drives an external N-Channel MOSFET, allowing for precise control over the inrush current during board insertion.
  • Automatic Retry or Latch Off: In the event of a fault, the device can be configured to either automatically attempt to restart the power or to latch off, providing a tailored response to system conditions.
  • Undervoltage Lockout: This feature ensures that the controller remains off if the supply voltage is inadequate, thus protecting the system from operating under potentially harmful conditions.

Applications:

The LT1641-2CS8#TRPBF is versatile and can be used in various applications that require reliable power management. It is particularly useful in:

  • Server Backplanes
  • Network Routers and Switches
  • Industrial Systems
  • Telecommunications Equipment
  • Datacom Infrastructure

With its robust feature set and high reliability, the LT1641-2CS8#TRPBF hot swap controller is an essential component for designers looking to create safe and efficient electronic systems. Its ability to minimize downtime and protect against electrical faults makes it an invaluable part of modern electronics design.
