Overview

The OR2C06A-2T144 is a Field-Programmable Gate Array (FPGA) from Lattice Semiconductor Corporation, belonging to the ORCA 2C family. It is designed to provide a flexible and cost-effective solution for implementing custom digital logic circuits. This FPGA offers a balance of programmable logic, routing resources, and I/O capabilities. The OR2C06A-2T144 is often used in applications such as telecommunications, networking, industrial control, and embedded systems that require programmability and fast prototyping.

Applications

• Telecommunications Equipment
• Networking Devices
• Industrial Control Systems
• Embedded Systems
• Data Processing

Features

• Programmable Logic: Features a configurable array of logic blocks for implementing custom digital circuits.
• Flexible Routing Architecture: Provides a hierarchical routing structure for connecting logic blocks and I/O pins efficiently.
• On-Chip Memory: Includes embedded memory blocks for data storage and processing.
• Versatile I/O: Supports a wide range of I/O standards and voltages to interface with different external devices.
• JTAG Configuration: Facilitates easy programming and debugging through the JTAG interface.

Benefits

• Design Flexibility: Allows for customization and reconfiguration of hardware to meet specific application requirements.
• Reduced Time-to-Market: Enables rapid prototyping and development, significantly reducing the design cycle time.
• Cost-Effectiveness: Offers a cost-optimized solution compared to custom ASIC designs, especially for low to medium volume production.
• Easy Programming and Debugging: Supported by Lattice's design software and the standard JTAG interface.
• Adaptable Design: Allows for design changes and updates without requiring hardware modifications, providing greater adaptability to evolving requirements.

Additional Details

The OR2C06A-2T144 is packaged in a T144 package. The '-2' in the part number typically indicates a speed grade. It requires a supply voltage, often around 3.3V or 5V, but the specific voltage depends on the configuration and I/O requirements. Designers can utilize Lattice's design software to create and implement their designs on the OR2C06A-2T144. The manufacturer's datasheet provides detailed specifications, including the number of logic cells, memory size, I/O pin count, and power consumption characteristics. This FPGA is a suitable option for applications where flexibility, programmability, and rapid prototyping are critical factors.
