The LC4128ZC-75M132I is a high-performance Complex Programmable Logic Device (CPLD) manufactured by Lattice Semiconductor Corporation. This CPLD is designed for a wide range of applications requiring programmable logic, including control logic, address decoding, and state machine implementation. Its non-volatile configuration, high speed, and low power consumption make it ideal for use in industrial control, communication systems, and embedded applications.

Applications

• Industrial control systems: Used in programmable logic controllers (PLCs), motor drives, and process control equipment.
• Communication systems: Incorporated into routers, switches, and network interface cards (NICs).
• Embedded systems: Found in automotive electronics, medical devices, and consumer electronics.
• Address decoding: Used in memory controllers and peripheral interfaces.
• State machine implementation: Implements control logic for complex systems.

Features

• Logic Cells: 128 macrocells
• Registers: 128 flip-flops
• I/O Pins: 100 available I/O
• Propagation Delay: 7.5 ns
• Supply Voltage: 3.3V
• Operating Temperature Range: -40°C to +85°C
• Package: 132-pin PQFP

Benefits

• Flexible Logic Implementation: Allows for the implementation of custom logic functions.
• High Speed Performance: Provides fast propagation delays for high-speed applications.
• Low Power Consumption: Minimizes power dissipation in battery-powered devices.
• Non-Volatile Configuration: Retains configuration data even when power is removed.
• Easy Prototyping: Simplifies design and development with programmable logic.

Additional Details

The LC4128ZC-75M132I CPLD utilizes advanced CMOS technology to achieve its high performance and low power consumption. The non-volatile configuration memory allows the device to be programmed and reprogrammed multiple times. The device is supported by Lattice's design software, which provides a comprehensive development environment for designing and implementing custom logic functions. The 132-pin PQFP package provides a high density of I/O pins for interfacing with external devices. Lattice CPLDs are known for their quality, reliability, and performance, making them a popular choice for a wide range of programmable logic applications.
