GAL22V10D-15LPN real image GAL22V10D-15LPN Real Image
Same model may have multiple batches, images only for reference.
GAL22V10D-15LPN real image GAL22V10D-15LPN Real Image
GAL22V10D-15LPN real image GAL22V10D-15LPN Real Image
Same model may have multiple batches, images only for reference.

GAL22V10D-15LPN

Part No GAL22V10D-15LPN
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 10MC 15NS 24DIP
Datasheet
GAL22V10D-15LPN Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Tube/Rail
Status Obsolete(EOL)
Programmable Type EE PLD
Delay Time tpd(1) Max 15.0ns
Voltage Supply - Internal 4.75 V to 5.25 V
Number of Macrocells 10
Temperature Range - Operating 0°C to 75°C (TA)
Mounting Through Hole
Case / Package 24-PDIP
Win Source Part Number 35874-GAL22V10D-15LPN
Family Name GAL22V10D
Introduction Date August 22, 2008
ECCN EAR99
Country of Origin Indonesia, Philippines
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GAL22V10D-15LPN CAD Model

Description

The Lattice Semiconductor Corporation GAL22V10D-15LPN is a programmable EE PLD.

  • Delay Time Max: 15.0ns
  • Macrocells: 10
  • Voltage Supply: 4.75V to 5.25V
  • Package: 24-PDIP
  • Mounting Type: Through Hole
  • Family: GAL22V10D
  • Status: Obsolete (EOL)
  • Operating Temperature: 0°C to 75°C (TA)
  • Supply and Demand: Balanced
