The KPBA-3010CGKSURKC is a surface-mount LED indicator manufactured by Kingbright Corporation. This bi-color LED is designed for various indication applications where visual status is crucial.

Applications:

• Front panel indicators in electronic devices
• Status indicators in industrial control systems
• Backlighting for small displays and keypads
• Diagnostic indicators in communication equipment
• Consumer electronics such as toys and appliances

Features:

• Bi-color LED: Combines green and red colors in a single package, enabling dual-state indication.
• Surface Mount Device (SMD): Designed for automated assembly processes, reducing manufacturing costs.
• Compact Package: Small footprint allows for high-density placement on PCBs.
• Low Current Operation: Efficient energy consumption for extended battery life in portable devices.
• Wide Viewing Angle: Provides clear visibility from various angles.
• RoHS Compliant: Meets environmental regulations for hazardous substances.

Benefits:

• Versatile Indication: The bi-color functionality allows for clear representation of different states or conditions, enhancing user understanding.
• Cost-Effective: SMD design lowers assembly costs and improves manufacturing efficiency.
• Space-Saving: The compact package enables integration into space-constrained applications.
• Energy Efficient: Low current consumption minimizes power usage and extends battery life.
• Reliable Performance: High-quality materials and manufacturing processes ensure long-term reliability.

Additional Details:

The KPBA-3010CGKSURKC LED utilizes a combination of AlGaAs and GaP semiconductor materials for the red and green emitters, respectively. The lens is typically made of epoxy resin. Forward voltage characteristics are around 2V for both colors, and typical luminous intensity values vary depending on the drive current. The device is commonly supplied on tape and reel for automated pick-and-place assembly.
