Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Connectors, Interconnects - Terminals - Quick Connects, Quick Disconnect Connectors
Mfr Keystone Electronics
Package Bulk
Product Status Active
Terminal Type Standard
Gender Male
Tab Width 0.187" (4.75mm)
Tab Thickness 0.020" (0.51mm)
Length - Overall 0.850" (21.59mm)
Termination Crimp
Wire Gauge 18-22 AWG
Insulation Non-Mating End Insulated
Mounting Type Free Hanging (In-Line)
Color Red
Contact Material Copper
Contact Finish Tin
Insulation Diameter 0.145" (3.68mm)
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 551236-8286
Ultra Librarian 3D Model Ultra Librarian 8286 CAD Model

Description

The 551236-8286 is a red male quick disconnect connector from Keystone Electronics.

  • Connector Type: Quick Disconnect
  • Gender: Male
  • Termination: Crimp
  • Contact Finish: Tin
  • Overall Length: 0.850 inches (21.59mm)
  • Tab Width: 0.187 inches (4.75mm)
  • Tab Thickness: 0.020 inches (0.51mm)
  • Insulation Diameter: 0.145 inches (3.68mm)
  • Mounting Type: Free Hanging (In-Line)
  • Insulation: Non-Mating End Insulated
  • Wire Gauge: 18-22 AWG
  • Package Quantity: 100 pieces
  • Contact Material: Copper
