Same model may have multiple batches, images only for reference.
SS26V-R100330 Kemet – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

SS26V-R100330

Part No SS26V-R100330
Manufacturer Kemet
Catalog Common Mode Chokes
Description CMC 33MH 1A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 33 mH @ 1 kHz
Current Rating (Max) 1A
DC Resistance (DCR) (Max) 700mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -25°C ~ 120°C
Mounting Type Through Hole
Size / Dimension 1.024" L x 0.807" W (26.00mm x 20.50mm)
Height (Max) 1.201" (30.50mm)
Case / Package Vertical, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530632-SS26V-R100330
Ultra Librarian 3D Model Ultra Librarian SS26V-R100330 CAD Model
