The Kemet 9004AA105M300CV680 is a multilayer ceramic capacitor (MLCC). MLCCs are known for their small size, high capacitance, and excellent performance characteristics across a wide range of frequencies and temperatures. The '9004AA' likely specifies a particular series within Kemet's MLCC offerings, while '105M' indicates a capacitance value (1.0 x 10^6 pF or 1.0 µF) and tolerance (M = ±20%). '300CV' refers to the voltage rating (30V) and dielectric material (CV = X5R). The '680' is often a manufacturing or lot code.

Applications

• Bypass and decoupling capacitors in digital circuits
• Filtering in power supplies
• Signal conditioning
• DC blocking
• General-purpose applications in electronic circuits

Features

• High Capacitance: Provides a significant capacitance value in a small package.
• Multilayer Construction: Offers excellent volumetric efficiency.
• X5R Dielectric: Stable capacitance over temperature variations.
• Low ESR and ESL: Minimizes losses and enhances high-frequency performance.
• RoHS Compliant: Meets environmental standards.

Benefits

• Effective Noise Reduction: Filters out unwanted noise and ripple in electronic circuits.
• Stable Performance: Maintains consistent capacitance over a wide temperature range.
• Compact Size: Saves valuable board space.
• Reliable Operation: Ensures long-term performance in demanding environments.
• Improved Signal Integrity: Provides clean and stable signals for accurate circuit operation.

Additional Details
