The S7B-XH-A-1(LF)(SN) is a 7-position housing from the XH series manufactured by JST Sales America Inc. It's a key component used in wire-to-board connections within electronic assemblies. This housing is designed to securely hold crimp contacts, providing a reliable and durable connection for various applications. The 'LF' designation indicates that it is lead-free, complying with RoHS standards. The 'SN' is likely a plating code.

Applications

• Power supplies
• Consumer electronics
• Industrial control equipment
• Security systems
• Automotive electronics

Features

• 7-position housing
• XH series connector
• Wire-to-board connection
• Accepts crimp contacts
• Lead-free (RoHS compliant)

Benefits

• Provides secure and reliable wire-to-board connections
• Complies with environmental regulations (RoHS)
• Offers a compact and space-saving design
• Facilitates easy and efficient assembly
• Ensures long-term performance and durability

Additional Details

The S7B-XH-A-1(LF)(SN) housing is designed to be used with compatible XH series crimp contacts and headers to create a complete wire-to-board connection system. The housing is typically made from a durable plastic material that provides electrical insulation and mechanical protection for the contacts. The design of the housing ensures proper alignment and retention of the contacts, preventing accidental disconnections. The 2.5mm pitch XH series are very popular and versatile. The (LF) designation assures users of compliance with environmental directives concerning lead content in electronics manufacturing.

Proper crimping tools are required for terminating wires with the appropriate crimp contacts. This ensures a gas-tight and reliable connection between the wire and the contact. Wire size and insulation diameter should also be carefully considered to ensure proper fit and performance within the connector system. The complete XH series offers a wide range of options in terms of the number of positions and mounting styles, providing flexibility for various design requirements. The XH Series by JST is a very common 2.5mm pitch system.
