Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Packaging Tube
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 200V
Id - Continuous Drain Current 74A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 30mOhm at 500mA, 10V
Gate Source Voltage(th) (Maximum) at Id 4V at 4mA
Gate Charge (Qg) (Maximum) at Vgs 280nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 5400pF at 25V
Power Dissipation (Maximum) 360W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Supplier Device Package TO-247AD (IXFH)
Manufacturer Package TO-247-3
Manufacturer Pack Quantity 30
MSL Level 1 (Unlimited)
Win Source Part Number 1191070-IXFH74N20
Manufacturer Homepage www.ixys.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IXFH74N20 CAD Model

Description

The IXYS MOSFET is an N-channel transistor polarity with a drive voltage (Max Rds On, Min Rds On) of 10V.

  • Manufacturer: IXYS
  • Channel Type: N-channel
  • Drive Voltage: 10V
  • Category: Discrete semiconductor products
  • Mounting: Through hole technology
  • Package: TO-247AD (IXFH)
  • Power Dissipation (maximum): 360W
  • Vds - Drain-Source Breakdown Voltage: 200V
  • Id - Continuous Drain Current: 74A
  • Gate Source Voltage (th) (maximum) @ Id: 4V @ 4mA
  • Gate Charge (Qg) (maximum) @ Vgs: 280nC @ 10V
  • Input Capacitance (Ciss) (maximum) @ Vds: 5400pF @ 25V
  • Status: Obsolete
  • Popularity: Medium
  • Supply and Demand Status: Sufficient
