DSEI12-10A Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1000V (1kV)
Current - Average Rectified (Io) 12A
Voltage - Forward (Vf) (Max) @ If 2.7V @ 12A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 60ns
Current - Reverse Leakage @ Vr 250μA @ 1000V
Mounting Through Hole
Case / Package TO-220AC
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 050933-DSEI12-10A
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DSEI12-10A CAD Model

Description

DSEI12-10A - Power-efficient Rectifier Diode

The DSEI12-10A rectifier diode offers an outstanding balance of efficiency and performance. It is engineered for high-frequency applications, ensuring that power loss is minimized while maximizing durability.

Applications/Projects:

  • AC-DC conversion
  • Power factor correction circuits
  • Charger applications
  • Industrial drive systems

Features and Benefits:

  • Optimized for high-frequency switching applications.
  • Superior junction temperature capability.
  • Low leakage current reduces power waste.
  • Easy to mount with a TO-220AC package.

Additional Details: This component is designed to meet rigorous standards, ensuring reliability in demanding applications.
