Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr IXYS
Series CPC, OptoMOS®
Package Tube
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.2VDC
Voltage - Load 0 V ~ 60 V
Load Current 400 mA
On-State Resistance (Max) 2 Ohms
Termination Style Gull Wing
Package / Case 4-SOP (0.150", 3.81mm)
Supplier Device Package 4-SOP
Base Product Number CPC1014
Standard Package 100 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0030
California Prop 65 Warning Information
Win Source Part Number 580100-CPC1014N
Ultra Librarian 3D Model Ultra Librarian CPC1014N CAD Model

Description

The IXYS 580100-CPC1014N is a solid-state relay from the CPC series.

  • Series: CPC
  • Termination Style: Gull Wing
  • Package: 4-SOP
  • Voltage Input: 1.2VDC
  • Load Current: 400mA
  • On-State Resistance: Maximum 2 Ohms
  • Circuit Configuration: Single-Pole, Normally Open (SPST-NO), providing one form A circuit
  • Mounting: Surface Mountable
  • Standard Package: 100 pcs
  • Product Status: Active
  • Compliance: Compliant with California Prop 65 regulations and is unaffected by REACH.
