Same model may have multiple batches, images only for reference.
ISP815XSM Isocom Components 2004 LTD
Same model may have multiple batches, images only for reference.

ISP815XSM

Part No ISP815XSM
Manufacturer Isocom Components 2004 LTD
Catalog Misc Products
Description HIGH DENSITY MOUNTING PHOTODARLINGTON OPTICALLY COUPLED ISOLATORS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Uncategorized
Manufacturer Isocom Components 2004 LTD
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 826294-ISP815XSM
Package Tube
Product Status Active
Number of Channels 1
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Min) 60% @ 1mA
Current Transfer Ratio (Max) 7500% @ 1mA
Rise / Fall Time (Typ) 60µs, 53µs
Input Type DC
Output Type Darlington
Voltage - Output (Max) 35V
Current - Output / Channel 80mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Max) 50mA
Vce Saturation (Max) 1V
Grade -
Operating Temperature -30°C ~ 100°C
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Supplier Device Package 4-SMD
Ultra Librarian 3D Model Ultra Librarian ISP815XSM CAD Model

Description

The Isocom Components 2004 LTD ISP815XSM is an optoisolator output that has a medium popularity in the market.

  • The supply and demand status is limited, and it is categorized as uncategorized.
  • The Isocom Components 2004 LTD ISP815XSM is a reliable and efficient optoisolator output that meets the requirements of most isolator applications.
