IS181GB Real Image IS181GB Real Image
Same model may have multiple batches, images only for reference.
IS181GB Real Image IS181GB Real Image
IS181GB Real Image IS181GB Real Image
Same model may have multiple batches, images only for reference.

IS181GB

Part No IS181GB
Manufacturer Isocom Components 2004 LTD
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS MINI-FLAT
Datasheet
IS181GB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Isocom Components 2004 LTD
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Rise and Fall Time 4μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Win Source Part Number 62105-IS181GB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian IS181GB CAD Model

Description

The IS181GB is an electronic component manufactured by Isocom Components 2004 LTD.

  • Type: isolator
  • Mounting: SMD (SMT)
  • Output Type: transistor
  • Forward Voltage: 1.2V
  • Input Type: DC
  • Channels: one
  • Vce Saturation (Max): 200mV
  • Isolation Voltage: 3750Vrms
  • Win Source Part Number: 62105-IS181GB
  • Popularity: high
  • Supply and Demand Status: limited
  • DC Current Transfer Ratio (Min): 100% @ 5mA
  • DC Current Transfer Ratio (Max): 600% @ 5mA
  • Rise and Fall Time: 4μs, 3μs
  • Output Voltage (Max): 80V
  • Channel Output Current: 50mA
  • Continuous Forward Current-Max: 50mA
  • Alternative parts (cross-reference): LTV-352T-V, TLP181(GB), and TLP181GBTPL
