BVS-A-R001-1.0 Isabellen
Same model may have multiple batches, images only for reference.

BVS-A-R001-1.0

Part No BVS-A-R001-1.0
Manufacturer Isabellen
Catalog Chip Resistor - Surface Mount
Description RESISTOR - ISA-WELD SHUNT, 0.001
Datasheet
BVS-A-R001-1.0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors - Chip Resistor - Surface Mount
Mfr Isabellen
Series BVS
Package Tape & Reel
Product Status Active
Resistance 1 mOhms
Tolerance ±1%
Power (Watts) 8W
Features Automotive AEC-Q200, Current Sense, Moisture Resistant
Temperature Coefficient ±50ppm/°C
Temperature Range - Operating -65°C ~ 170°C
Package / Case 3920 (1052 Metric)
Supplier Device Package 3920
Ratings AEC-Q200
Size / Dimension 0.394" L x 0.205" W (10.00mm x 5.20mm)
Number of Terminations 2
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.21.0090
Win Source Part Number 85620-BVS-A-R001-1.0
Ultra Librarian 3D Model Ultra Librarian BVS-A-R001-1.0 CAD Model

Description

BVS-A-R001-1.0 Precision Shunt Resistor

The BVS-A-R001-1.0 is a precision shunt resistor known for its accuracy and stability. It's tailored for applications needing precise current measurement and monitoring.

  • Features & Benefits:
    • High precision with a low resistance value of 0.001 ohm.
    • Excellent long-term stability.
    • Minimal temperature coefficient.
    • Compact and robust construction.
  • Applications & Projects:
    • Current sensing in battery management systems.
    • Power monitoring circuits.
    • Industrial automation systems.
    • Instrument calibration devices.
