ICM7556IPDZ Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Tube/Rail
Status Active
Type 555 Type, Timer/Oscillator (Dual)
Frequency 1MHz
Supply Voltage - Operating 2 V to 18 V
Operating Supply Current 120μA
Temperature Range - Operating -25°C to 85°C
Case / Package 14-PDIP
Mounting Through Hole
Win Source Part Number 017138-ICM7556IPDZ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian ICM7556IPDZ CAD Model

Description

The Intersil ICM7556IPDZ is a 555 Type, Timer/Oscillator (Dual) IC with a frequency of 1MHz. It has a temperature range of -25°C to 85°C and operates on a supply voltage of 2 V to 18 V with an operating supply current of 120μA. The IC comes in a 14-PDIP package and is commonly used in industrial applications.
