ICM7555IPAZ Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Tube/Rail
Status Active
Type 555 Type, Timer/Oscillator (Single)
Frequency 1MHz
Supply Voltage - Operating 2 V to 18 V
Operating Supply Current 60μA
Temperature Range - Operating -25°C to 85°C
Case / Package 8-PDIP
Mounting Through Hole
Win Source Part Number 068432-ICM7555IPAZ
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Clock & Timing
Ultra Librarian 3D Model Ultra Librarian ICM7555IPAZ CAD Model

Description

The ICM7555IPAZ is a timer/oscillator (single) integrated circuit manufactured by Intersil. It has a frequency of 1MHz and is a part of the Integrated Circuits category. The supply and demand status of this product is balanced. The ICM7555IPAZ is used in clock and timing applications and has a supply voltage operating range of 2V to 18V.
