Same model may have multiple batches, images only for reference.
PVT422SPBF Real Image
Same model may have multiple batches, images only for reference.

PVT422SPBF

Part No PVT422SPBF
Manufacturer Infineon Technologies
Catalog Solid State Relays
Description IC RELAY PHOTOVO 400V 120MA 8SMD
Datasheet
PVT422SPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Circuit DPST (2 Form A)
Output Type AC, DC
Max On Resistance 35 Ohm
Load Current 120mA
Voltage - Input 1.2VDC
Voltage - Load 0 to 400 V
Mounting SMD (SMT)
Termination Style Gull Wing
Case / Package 8-SMT
Relay Type Relay
Win Source Part Number 1090810-PVT422SPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PVT422SPBF CAD Model

Description

The Infineon Technologies PVT422SPBF is a DPST (2 Form A) relay with a load current of 120mA and a voltage load range of 0 to 400V.

  • Relay Type: DPST (2 Form A)
  • Load Current: 120mA
  • Voltage Load: 0 to 400V
  • Maximum On Resistance: 35 Ohm
  • Termination Style: Gull Wing
  • Package: 8-SMT
  • Application: Various Applications
  • Supply and Demand Status: Balanced
