IRSM807-105MHTR

Part No IRSM807-105MHTR
Manufacturer Infineon Technologies
Catalog PMIC - Full, Half - Bridge Drivers
Description IC HALF BRIDGE DRIVER 10A 31PQFN
Datasheet
IRSM807-105MHTR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Full Half-Bridge Drivers
Mfr Infineon Technologies
Series µIPM™
Package Tape & Reel
Product Status Active
Output Configuration Half Bridge
Applications AC Motors
Interface Logic
Load Type Inductive
Technology UMOS
Rds On (Typ) 580mOhm
Current - Output / Channel 10A
Voltage - Supply 13.5V ~ 16.5V
Voltage - Load 400V (Max)
Temperature Range - Operating 150°C (TJ)
Features Bootstrap Circuit
Fault Protection UVLO
Mounting Type Surface Mount
Package / Case 31-PowerVQFN
Supplier Device Package 31-PQFN (8x9)
Base Product Number IRSM807
Standard Package 2,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 875304-IRSM807-105MHTR
Ultra Librarian 3D Model Ultra Librarian IRSM807-105MHTR CAD Model

Description

The IRSM807-105MHTR is a full half-bridge driver integrated circuit designed for power management applications.

  • Series: µIPM™ series from Infineon Technologies
  • Feature: bootstrap circuit for efficient operation
  • Current Output: 10A
  • Voltage Load: 400V
  • Technology: UMOS
  • Rds On: 580mOhm, minimizing power losses
  • Voltage Supply Range: 13.5V to 16.5V
  • Temperature Range: up to 150°C
  • Package: compact 31-PowerVQFN package
  • Application: AC motors
  • Status: active product from Infineon Technologies
