IRS2113STRPBF

Name: IRS2113STRPBF
Brand: Infineon Technologies
SKU: 161790
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRS2113STRPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC DRIVER HIGH/LOW SIDE 16-SOIC
Datasheet	IRS2113STRPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	10 V to 20 V
Logic Voltage - VIL, VIH	6V, 9.5V
Current - Peak Output (Source, Sink)	2.5A, 2.5A
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	25ns, 17ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	16-SOIC
Win Source Part Number	017828-IRS2113STRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRS2113
Introduction Date	May 03, 2006
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian IRS2113STRPBF CAD Model

Description

The Infineon Technologies IRS2113STRPBF is an independent channel type half-bridge driver with two drivers.

Channel Type: independent
Input Type: non-inverting
Gate Type: IGBT and N-Channel MOSFET
Logic Voltage: 6V to 9.5V
Current Peak Output: 2.5A for both source and sink
High Side Voltage: 600V
Mounting: on a reel
Type: active integrated circuit
Temperature Range: -40°C to 150°C
Supply Voltage Range: 10V to 20V
Rise Time: 25ns
Fall Time: 17ns
Popularity Rating: high
Supply and Demand Status: balanced
