IRS2112PBF

Name: IRS2112PBF
Brand: Infineon Technologies
SKU: 462939
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	IRS2112PBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC DRIVER HI/LO SIDE 600V 14-DIP
Datasheet	IRS2112PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	10 V to 20 V
Logic Voltage - VIL, VIH	6V, 9.5V
Current - Peak Output (Source, Sink)	290mA, 600mA
Input Type	Non-Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	75ns, 35ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	14-DIP
Win Source Part Number	1047755-IRS2112PBF
Popularity	Medium
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian IRS2112PBF CAD Model

Description

The Infineon Technologies IRS2112PBF is an independent channel type electronic component.

Configuration: Half-bridge driven
Drivers: Two
Gate Type Compatibility: IGBT and N-Channel MOSFET
Input Type: Non-inverting
Operating Temperature: -40°C to 150°C
Operating Voltage: 10V to 20V
Logic Voltage: 6V to 9.5V
Peak Output Current (source): 290mA
Peak Output Current (sink): 600mA
High Side Voltage (max): 600V
Package: 14-DIP
Popularity: Medium
