IRS21094STRPBF Infineon Technologies IRS21094STRPBF Real Image IRS21094STRPBF real image IRS21094STRPBF real image 2
Same model may have multiple batches, images only for reference.
IRS21094STRPBF Infineon Technologies IRS21094STRPBF Real Image IRS21094STRPBF real image IRS21094STRPBF real image 2
IRS21094STRPBF Infineon Technologies IRS21094STRPBF Real Image IRS21094STRPBF real image IRS21094STRPBF real image 2
Same model may have multiple batches, images only for reference.

IRS21094STRPBF

Part No IRS21094STRPBF
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description Driver 600V 0.6A 2-OUT High and Low Side Half Brdg Inv/Non-Inv 14-Pin SOIC N T/R / IC DVR HALF BRIDGE 14-SOIC
Datasheet
IRS21094STRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Synchronous
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Supply Voltage - Operating 10 V to 20 V
Logic Voltage - VIL, VIH 0.8V, 2.5V
Current - Peak Output (Source, Sink) 290mA, 600mA
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 600V
Rise and Fall Time 100ns, 35ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 069785-IRS21094STRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRS21094
Introduction Date May 04, 2006
ECCN EAR99
Country of Origin China, Indonesia, Malaysia, Thailand, United States of America
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian IRS21094STRPBF CAD Model

Description

The Infineon Technologies 069785-IRS21094STRPBF is a half-bridge synchronous channel type integrated circuit.

  • Channel Type: synchronous
  • Number of Drivers: two drivers
  • Gate Type: IGBT and N-Channel MOSFET
  • Logic Voltage - VIL, VIH: 0.8V, 2.5V
  • Current - Peak Output (source, sink): 290mA, 600mA
  • High Side Voltage - Max (bootstrap): 600V
  • Supply Voltage Range: 10 V to 20 V
  • Temperature Range: -40°C to 150°C
  • Packaging: 14-SOIC
  • Product Category: integrated circuits
  • Status: active
  • Supply and Demand Status: balanced
