Same model may have multiple batches, images only for reference.

IRGS6B60KDPBF

Name: IRGS6B60KDPBF
Brand: Infineon Technologies
SKU: 161327
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRGS6B60KDPBF
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	IGBT 600V 13A 90W D2PAK
Datasheet	IRGS6B60KDPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
IGBT Type	NPT
VCEO Maximum Collector-Emitter Breakdown Voltage	600V
Maximum Current Collector	13A
Pulsed Collector Current	26A
Collector-emitter saturation voltage(Max)	2.2V @ 15V, 5A
Maximum Power Dissipation	90W
Total Switching Energy(Ets)	110μJ (on), 135μJ (off)
Input Type	Standard
Gate Charge	18.2nC
Turn-on and Turn-off delay time	25ns/215ns
Testing Conditions	400V, 5A, 100 Ohm, 15V
Reverse Recovery Time (trr)	70ns
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	D2PAK
Win Source Part Number	040785-IRGS6B60KDPBF
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRGS6B60KDPBF CAD Model

Description

The Infineon Technologies 040785-IRGS6B60KDPBF is a high-performance MOSFET designed for use in a variety of applications.

Maximum Drain-Source Breakdown Voltage: 600V
Maximum Current Collector: 13A
Maximum Power Dissipation: 90W
Package: D2PAK
Mounting: SMT
Gate Charge: 18.2nC
Total Switching Energy: 110μJ (on) and 135μJ (off)
Turn-On Delay Time: 25ns
Turn-Off Delay Time: 215ns
Supply and Demand Status: Limited

The Infineon Technologies 040785-IRGS6B60KDPBF is an active product, but its supply and demand status is limited.
