IRG4PC40SPBF

Name: IRG4PC40SPBF
Brand: Infineon Technologies
SKU: 161189
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRG4PC40SPBF
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	IGBT 600V 60A 160W TO247AC
Datasheet	IRG4PC40SPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Bulk
Status	Active
VCEO Maximum Collector-Emitter Breakdown Voltage	600V
Maximum Current Collector	60A
Pulsed Collector Current	120A
Collector-emitter saturation voltage(Max)	1.5V @ 15V, 31A
Maximum Power Dissipation	160W
Total Switching Energy(Ets)	450μJ (on), 6.5mJ (off)
Input Type	Standard
Gate Charge	100nC
Turn-on and Turn-off delay time	22ns/650ns
Testing Conditions	480V, 31A, 10 Ohm, 15V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	TO-247AC
Win Source Part Number	069644-IRG4PC40SPBF
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRG4PC40SPBF CAD Model

Description

The Infineon Technologies 069644-IRG4PC40SPBF is a TO-247AC packaged IGBT with a maximum collector-emitter breakdown voltage of 600V and a maximum collector current of 60A.

Maximum Power Dissipation: 160W
Pulsed Collector Current: 120A
Collector-Emitter Saturation Voltage: 1.5V @ 15V, 31A
Total Switching Energy: 450μJ (on) and 6.5mJ (off)
Turn-On and Turn-Off Delay Time: 22ns/650ns
