IRG4BC30UDPBF Real Image IRG4BC30UDPBF Real Image1 IRG4BC30UDPBF Real Image2
Same model may have multiple batches, images only for reference.
IRG4BC30UDPBF Real Image IRG4BC30UDPBF Real Image1 IRG4BC30UDPBF Real Image2
IRG4BC30UDPBF Real Image IRG4BC30UDPBF Real Image1 IRG4BC30UDPBF Real Image2
Same model may have multiple batches, images only for reference.

IRG4BC30UDPBF

Part No IRG4BC30UDPBF
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 600V 23A 100W TO220AB
Datasheet
IRG4BC30UDPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 23A
Pulsed Collector Current 92A
Collector-emitter saturation voltage(Max) 2.1V @ 15V, 12A
Maximum Power Dissipation 100W
Total Switching Energy(Ets) 380μJ (on), 160μJ (off)
Input Type Standard
Gate Charge 50nC
Turn-on and Turn-off delay time 40ns/91ns
Testing Conditions 480V, 12A, 23 Ohm, 15V
Reverse Recovery Time (trr) 42ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 069634-IRG4BC30UDPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRG4BC30UDPBF CAD Model

Description

The Infineon Technologies IRG4BC30UDPBF is an electronic component manufactured by Infineon Technologies.

  • Supply and Demand Status: Balanced
  • Win Source Part Number: 069634-IRG4BC30UDPBF
  • Category: Discrete Semiconductor Products
  • Packaging: Tube/Rail
  • Mounting: Through Hole
  • Reverse Recovery Time (trr): 42ns
  • IGBT Type: -
  • Input Type: Standard
  • Gate Charge: 50nC
  • Maximum Current Collector: 23A
  • VCEO Maximum Collector-Emitter Breakdown Voltage: 600V
  • Maximum Power Dissipation: 100W
  • Pulsed Collector Current: 92A
  • Collector-Emitter Saturation Voltage (max): 2.1V @ 15V, 12A
  • Total Switching Energy (Ets) (on): 380μJ
  • Total Switching Energy (Ets) (off): 160μJ
  • Turn-On Delay Time: 40ns
  • Turn-Off Delay Time: 91ns
  • Testing Conditions: 480V, 12A, 23 Ohm, 15V
