Same model may have multiple batches, images only for reference.

IRFS7730TRL7PP

Name: IRFS7730TRL7PP
Brand: Infineon Technologies
SKU: 803463
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRFS7730TRL7PP
Manufacturer	Infineon Technologies
Catalog	FETs - Single
Description	MOSFET N-CH 75V 240A D2PAK
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Infineon Technologies
Packaging	Reel
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	75V
Current - Continuous Drain (Id) at 25°C	240A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Rds On (Maximum) at Id, Vgs	2mOhm at 100A, 10V
Vgs(th) (Maximum) at Id	3.7V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	428nC at 10V
Maximum Vgs	±20V
Input Capacitance (Ciss) (Maximum) at Vds	13970pF at 25V
Power Dissipation (Maximum)	375W (Tc)
Temperature Range - Operating	-55°C ~ 175°C
Mounting Style	SMD
Supplier Device Package	D2PAK (7-Lead)
Manufacturer Package	TO-263-7, D2Pak (6 Leads + Tab)
Manufacturer Pack Quantity	800
MSL Level	1 (Unlimited)
Popularity	Medium
Supply and Demand Status	Balance
Win Source Part Number	803463-IRFS7730TRL7PP
Ultra Librarian 3D Model	Ultra Librarian IRFS7730TRL7PP CAD Model

Description

The Infineon Technologies IRFS7730TRL7PP is an N-channel MOSFET designed for use in a variety of applications.

Drain to Source Voltage (Vdss): 75V
Maximum Power Dissipation: 375W
Mounting Type: Surface Mount
Package: TO-263-7, D2Pak (6 Leads + Tab)
Popularity: Medium
Manufacturer Pack Quantity: 800
Halogen Free Compliant: Yes
MSL Level: 1 (unlimited)
Maximum Gate Voltage (Vgs): ±20V
Continuous Drain Current (Id) @ 25°C: 240A
