Same model may have multiple batches, images only for reference.

IRF100P219AKMA1

Name: IRF100P219AKMA1
Brand: Infineon Technologies
SKU: 1065480
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	IRF100P219AKMA1
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 100V TO247AC / N-Channel 100 V 203A (Tc) 3.8W (Ta), 341W (Tc) Through Hole PG-TO247-3
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr	Infineon Technologies
Series	StrongIRFET™
Package	Tube
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	100 V
Current - Continuous Drain (Id) @ 25°C	203A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Rds On (Max) @ Id, Vgs	1.7mOhm @ 100A, 10V
Vgs(th) (Max) @ Id	3.8V @ 278µA
Gate Charge (Qg) (Max) @ Vgs	210 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	12020 pF @ 50 V
Power Dissipation (Max)	3.8W (Ta), 341W (Tc)
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	PG-TO247-3
Package / Case	TO-247-3
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Other Names	SP005537805,448-IRF100P219AKMA1
Standard Package	25
Win Source Part Number	1065480-IRF100P219AKMA1
Ultra Librarian 3D Model	Ultra Librarian IRF100P219AKMA1 CAD Model

Alternative Products

Description

The IRF100P219AKMA1 is a N-Channel MOSFET transistor with a drain to source voltage (Vdss) of 100 V and a continuous drain current (Id) of 203A (Tc) @ 25°C.

Type: N-Channel MOSFET
Drain to Source Voltage (Vdss): 100 V
Continuous Drain Current (Id): 203A (Tc) @ 25°C
On-Resistance (Max): 1.7mOhm @ 100A, 10V
Series: StrongIRFET™
Package: TO-247-3
Supplier Device Package: PG-TO247-3
Gate Charge (Qg): 210 nC @ 10 V
Input Capacitance (Ciss): 12020 pF @ 50 V
Applications: Power supplies and motor control
