IR2102SPBF

Name: IR2102SPBF
Brand: Infineon Technologies
SKU: 158822
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IR2102SPBF
Manufacturer	Infineon Technologies
Catalog	PMIC - Gate Drivers
Description	IC DRIVER HI/LOW SIDE 8-SOIC
Datasheet	IR2102SPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
Driven Configuration	Half-Bridge
Channel Type	Independent
Number of Drivers	2
Gate Type	IGBT, N-Channel MOSFET
Supply Voltage - Operating	10 V to 20 V
Logic Voltage - VIL, VIH	0.8V, 3V
Current - Peak Output (Source, Sink)	210mA, 360mA
Input Type	Inverting
High Side Voltage - Max (Bootstrap)	600V
Rise and Fall Time	100ns, 50ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	114788-IR2102SPBF
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IR2102SPBF CAD Model

Description

The Infineon Technologies 114788-IR2102SPBF is an integrated circuit used as a gate driver for IGBT and N-channel MOSFETs.

Mounting: SMD (SMT)
Package: Tube/rail
Channels: Two independent channels
Input Type: Inverting
Driven Configuration: Half-bridge
Gate Types: IGBT and N-channel MOSFET
Logic Voltage - VIL, VIH: 0.8V, 3V
Current Peak Output (source, sink): 210mA, 360mA
High Side Voltage - Max (bootstrap): 600V
Category: Integrated Circuits
Popularity: Medium
Temperature Range: -40°C to 150°C (TJ)
Case/Package: 8-SOIC
Supply Voltage - Operating: 10V to 20V
Rise Time: 100ns
Fall Time: 50ns
Supply and Demand Status: Balanced
