IKW40T120

Name: IKW40T120
Brand: Infineon Technologies
SKU: 156421
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IKW40T120
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	Trans IGBT Chip N-CH 1200V 75A 270000mW 3-Pin(3+Tab) TO-247 Tube / IGBT 1200V 75A 270W TO247-3
Datasheet	IKW40T120 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
IGBT Type	NPT, Trench Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage	1200V
Maximum Current Collector	75A
Pulsed Collector Current	105A
Collector-emitter saturation voltage(Max)	2.3V @ 15V, 40A
Maximum Power Dissipation	270W
Total Switching Energy(Ets)	6.5mJ
Input Type	Standard
Gate Charge	203nC
Turn-on and Turn-off delay time	48ns/480ns
Testing Conditions	600V, 40A, 15 Ohm, 15V
Reverse Recovery Time (trr)	240ns
Temperature Range - Operating	-40°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	PG-TO247-3
Win Source Part Number	205138-IKW40T120
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IKW40T120
Introduction Date	July 02, 2002
ECCN	EAR99
Country of Origin	China, Philippines
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IKW40T120 CAD Model

Description

The IKW40T120 is an NPT, Trench Field Stop IGBT from Infineon Technologies.

Maximum Collector-Emitter Breakdown Voltage: 1200V
Maximum Collector Current: 75A
Package: PG-TO247-3
Maximum Power Dissipation: 270W
Reverse Recovery Time: 240ns
Gate Charge: 203nC
Total Switching Energy: 6.5mJ
Turn-On and Turn-Off Delay Time: 48ns/480ns
Popularity: High
Halogen-Free: Yes
Estimated EOL Date: 2027
