Same model may have multiple batches, images only for reference.

IKW40N120H3

Name: IKW40N120H3
Brand: Infineon Technologies
SKU: 156418
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IKW40N120H3
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	IGBT 1200V 80A 483W TO247-3
Datasheet	IKW40N120H3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
IGBT Type	Trench Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage	1200V
Maximum Current Collector	80A
Pulsed Collector Current	160A
Collector-emitter saturation voltage(Max)	2.4V @ 15V, 40A
Maximum Power Dissipation	483W
Total Switching Energy(Ets)	4.4mJ
Input Type	Standard
Gate Charge	185nC
Turn-on and Turn-off delay time	30ns/290ns
Testing Conditions	600V, 40A, 12 Ohm, 15V
Reverse Recovery Time (trr)	355ns
Temperature Range - Operating	-40°C to 175°C (TJ)
Mounting	Through Hole
Case / Package	PG-TO247-3
Win Source Part Number	087381-IKW40N120H3
Family Name	IKW40N120H3
Introduction Date	February 10, 2010
ECCN	EAR99
Country of Origin	China, Philippines
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IKW40N120H3 CAD Model

Alternative Products

Description

The Infineon Technologies 087381-IKW40N120H3 is a Trench Field Stop IGBT with a maximum collector-emitter breakdown voltage of 1200V and a maximum collector current of 80A.

Maximum Collector-Emitter Breakdown Voltage: 1200V
Maximum Collector Current: 80A
Gate Charge: 185nC
Collector-Emitter Saturation Voltage: 2.4V @ 15V and 40A
Total Switching Energy: 4.4mJ
Turn-On and Turn-Off Delay Time: 30ns and 290ns respectively
Junction Temperature Range: -40°C to 175°C
Package: PG-TO247-3
