Same model may have multiple batches, images only for reference.
IGW30N60T Infineon Technologies
Same model may have multiple batches, images only for reference.

IGW30N60T

Part No IGW30N60T
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 600V 53A 200W TO247
Datasheet
IGW30N60T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
IGBT Type Trench Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 53A
Pulsed Collector Current 90A
Collector-emitter saturation voltage(Max) 1.8V @ 15V, 30A
Maximum Power Dissipation 200W
Total Switching Energy(Ets) 710μJ (on), 420μJ (off)
Input Type Standard
Gate Charge 130nC
Turn-on and Turn-off delay time 15ns/179ns
Testing Conditions 400V, 30A, 10.5 Ohm, 15V
Temperature Range - Operating -40°C to 175°C (TJ)
Mounting Through Hole
Case / Package PG-TO247-3
Win Source Part Number 017142-IGW30N60T
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IGW30N60T CAD Model

Description

The Infineon Technologies IGBT with a collector-emitter breakdown voltage of 600V is a Trench Field Stop electronic component that is widely used in various applications.

  • Maximum Collector Current: 53A
  • Maximum Power Dissipation: 200W
  • Package: PG-TO247-3
  • Gate Charge: 130nC
  • Turn-On and Turn-Off Delay Time: 15ns/179ns
  • Product Status: Active component under the Discrete Semiconductor Products category
  • Applications: Motor drives, power supplies, and inverters
