Same model may have multiple batches, images only for reference.
IDW80C65D2XKSA1
Same model may have multiple batches, images only for reference.

IDW80C65D2XKSA1

Part No IDW80C65D2XKSA1
Manufacturer Infineon Technologies
Catalog Diodes, Rectifiers - Arrays
Description DIODE 650V 80A CC RAPID2 TO247-3
Datasheet
IDW80C65D2XKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 51 Weeks
Features Diode Array 1 Pair Common Cathode Standard 650 V 40A Through Hole TO-247-3
Manufacturer Infineon Technologies
Series Rapid 2
Package Tube
Speed Fast Recovery =< 500ns, > 200mA (Io)
Mounting Through Hole
Package TO-247-3
Case / Package PG-TO247-3
Family Name IDW80C65
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Quantity per package 30
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 874411-IDW80C65D2XKSA1
Ultra Librarian 3D Model Ultra Librarian IDW80C65D2XKSA1 CAD Model

Description

The Infineon Technologies Rapid 2 diode array is a 1 pair common cathode standard with a 650 V voltage rating and 40A current rating.

  • Package: TO-247-3
  • Mounting: Through-hole
  • Recovery Speed: Less than 500ns and greater than 200mA (Io)
  • Family: IDW80C65
  • Category: Discrete Semiconductor Products
  • Supplied in: Tubes
  • Popularity: Medium
  • ECCN: EAR99 compliant
  • REACH: Unaffected
  • Supply and Demand Status: Limited
  • Units per Package: 30
  • Estimated Production Lead Time: 51 weeks
  • Threatened in the open market: 88 pct.
