The FS800R07A2E3B31BOSA1 is an EconoDUAL™ 3 module from Infineon Technologies, designed for high-power applications. It integrates IGBTs (Insulated Gate Bipolar Transistors) and diodes in a single package, offering efficient and reliable power conversion. This module is part of the EconoDUAL™ family, known for its robust design and ease of use in inverter applications.

Applications

• Industrial motor drives
• Renewable energy inverters (solar, wind)
• Traction inverters (electric vehicles, trains)
• Power supplies
• Uninterruptible Power Supplies (UPS)

Features

• EconoDUAL™ 3 package
• IGBT4 chip technology
• TrenchStop™ technology for low VCE(sat)
• Integrated temperature sensor (NTC)
• Pressfit contacts for auxiliary terminals
• High power density

Benefits

• Improved efficiency due to low switching losses.
• Reduced system size and cost due to high integration.
• Enhanced reliability with integrated temperature sensor for protection.
• Simplified assembly with pressfit auxiliary terminals.
• Optimized thermal performance due to the EconoDUAL™ package design.

Additional Details

The FS800R07A2E3B31BOSA1 module incorporates Infineon's IGBT4 chip technology, ensuring low conduction and switching losses, thereby improving overall system efficiency. The integrated NTC temperature sensor allows for precise temperature monitoring and control, protecting the module from overheating. The pressfit contacts simplify the assembly process, reducing manufacturing time and costs. This module is designed for applications requiring high power and reliability, such as industrial drives and renewable energy systems. The EconoDUAL™ 3 package provides excellent thermal performance, enabling the module to operate at high power levels. Its robust design and advanced features make it a suitable choice for demanding power conversion applications. The module is RoHS compliant, ensuring environmental safety.
