DD800S17K3_B2 eupec GmbH
Same model may have multiple batches, images only for reference.

DD800S17K3_B2

Part No DD800S17K3_B2
Manufacturer Infineon Technologies
Catalog Diodes, Rectifiers - Arrays
Description DIODE MODULE GP 1700V 800A
Datasheet
DD800S17K3_B2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Infineon Technologies
Package Bulk
Product Status Active
Diode Configuration 2 Independent
Technology Standard
Voltage - DC Reverse (Vr) (Max) 1700 V
Voltage - Forward (Vf) (Max) @ If 2.2 V @ 800 A
Speed Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 780 A @ 900 V
Operating Temperature - Junction -40°C ~ 125°C
Mounting Type Chassis Mount
Package / Case Module
Base Product Number DD800S17
Standard Package 2 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 584266-DD800S17K3_B2
Ultra Librarian 3D Model Ultra Librarian DD800S17K3_B2 CAD Model

Description

The 584266-DD800S17K3_B2 is a diode array designed for rectification applications.

  • Maximum DC Reverse Voltage: 1700V
  • Application: Standard Recovery
  • Forward Voltage: 2.2V @ 800A
  • Reverse Leakage Current: 780A @ 900V
  • Operating Temperature: -40°C to 125°C
  • Package: Module
  • Mounting Type: Chassis Mount
  • Manufacturer: Infineon Technologies
  • Status: Active
  • Standard Package: 2 pieces
