BTS724GXUMA1 Real Image BTS724GXUMA1 Real Image1 BTS724GXUMA1 Real Image2
Same model may have multiple batches, images only for reference.
BTS724GXUMA1 Real Image BTS724GXUMA1 Real Image1 BTS724GXUMA1 Real Image2
BTS724GXUMA1 Real Image BTS724GXUMA1 Real Image1 BTS724GXUMA1 Real Image2
Same model may have multiple batches, images only for reference.

BTS724GXUMA1

Part No BTS724GXUMA1
Manufacturer Infineon Technologies
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC HISIDE PWR SWITCH 4CH PDSO-20
Datasheet
BTS724GXUMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 4
Output Type N-Channel
Voltage - Load 5.5 V to 40 V
Supply Voltage - Operating Not Required
Current - Output (Max) 3A
Rds On (Typ) 70 mOhm
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package PG-DSO-20
Win Source Part Number 124062-BTS724GXUMA1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BTS724GXUMA1 CAD Model

Description

Overview

The BTS724GXUMA1 is a versatile high-side power switch tailored for both consumer and industrial applications. Its intelligent features offer solid protection and enhance system reliability.

Applications

  • Smart home devices
  • Automotive electronic control units
  • Battery management systems

Features and Benefits

  • Integrated protective functions to safeguard against overheating.
  • Capable of handling high current loads.
  • Compact and optimized for low-power applications.

Additional Details

The BTS724GXUMA1 stands out for its high tolerance and adaptability, making it ideal for use in evolving technological setups. Its flexible design ensures broad compatibility across various platforms. Note: Manufacturer's name for BTS724GXUMA1 is not specified.
