2ED21824S06JXUMA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

2ED21824S06JXUMA1

Part No 2ED21824S06JXUMA1
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description IC HALF BRIDGE GATE DRIVER 650V / Half-Bridge Gate Driver IC Non-Inverting PG-DSO-14-49
Datasheet
2ED21824S06JXUMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Gate Drivers
Mfr Infineon Technologies
Package Tape & Reel
Driven Configuration Half-Bridge
Channel Type Synchronous
Number of Drivers 1
Gate Type IGBT, N-Channel MOSFET
Voltage - Supply 10V ~ 20V
Logic Voltage - VIL, VIH 1.1V, 1.7V
Current - Peak Output (Source, Sink) 2.5A, 2.5A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 650 V
Rise / Fall Time (Typ) 15ns, 15ns
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting SMD (SMT)
Package / Case 14-SOIC (0.154", 3.90mm Width)
Supplier Device Package PG-DSO-14-49
Base Product Number 2ED21824
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names SP003244528,448-2ED21824S06JXUMA1TR,448-2ED21824S06JXUMA1CT,448-2ED21824S06JXUMA1DKR
Standard Package 2,500
Win Source Part Number 1036364-2ED21824S06JXUMA1
Ultra Librarian 3D Model Ultra Librarian 2ED21824S06JXUMA1 CAD Model

Description

The 1036364-2ED21824S06JXUMA1 from Infineon Technologies is an integrated circuit (IC) PMIC - Gate Drivers with a synchronous channel type and a non-inverting input type.

  • Manufacturer: Infineon Technologies
  • Category: IC PMIC - Gate Drivers
  • Channel Type: Synchronous
  • Input Type: Non-inverting
  • Driven Configuration: Half-bridge
  • Number of Drivers: 1
  • Gate Type: IGBT, N-Channel MOSFET
  • Logic Voltage - VIL, VIH: 1.1V, 1.7V
  • Current - Peak Output (Source, Sink): 2.5A, 2.5A
  • High Side Voltage - Max (Bootstrap): 650 V
  • Rise/Fall Time (Typ): 15ns, 15ns
  • Voltage Supply: 10V ~ 20V
  • Package/Case: 14-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: PG-DSO-14-49
  • Temperature Range: -40°C ~ 125°C (TA)
  • MSL Level: 3 (168 Hours)
  • ECCN: EAR99
  • REACH Status: REACH Unaffected
  • HTSUS: 8542.39.0001
