The PEEL22CV10AJ-15 is a high-performance Programmable Electrically Erasable Logic (PEEL) device manufactured by ICT. This device is designed to implement complex logic functions, reducing the need for numerous discrete components. The reprogrammability feature allows for design modifications and updates without requiring hardware changes, resulting in shorter development cycles and reduced costs.

Applications

• High-speed control systems: Used in applications demanding quick response times.
• Address decoding in memory systems: Used for generating chip select signals.
• State machine implementation: Controls complex sequential logic.
• Peripheral device interfacing: Facilitates data exchange between a processor and peripheral components.
• Data encryption/decryption: Implements custom data security algorithms.

Features

• High-speed performance: With a propagation delay of 15ns, it ensures quick and efficient operation.
• Electrically erasable and reprogrammable: Allows for multiple programming cycles for design flexibility.
• Low power consumption: Efficiently minimizes power requirements.
• Versatile I/O configuration: Supports flexible assignment of input and output pins.
• TTL compatible: Compatible with standard TTL logic levels for seamless integration.

Benefits

• Increased system speed: High-speed performance enhances overall system responsiveness.
• Simplified system design: Reduces component count, simplifying board layout and design complexity.
• Improved design flexibility: Enables quick modifications and updates without hardware changes.
• Enhanced system reliability: Reduces the number of interconnects, boosting system reliability.
• Cost-effective solution: Reduces development and manufacturing costs via reprogrammability.

Additional Details

The PEEL22CV10AJ-15 operates on a 5V power supply and typically comes in a DIP (Dual In-line Package). The device consists of programmable AND and OR arrays, allowing implementation of customized logic. The device is re-programmable using electrical signals. This device has 22 inputs and 10 outputs.
