The H5PS1G83EFR-S6I-C is a 1Gb DDR2 SDRAM (Double Data Rate 2 Synchronous Dynamic Random-Access Memory) chip manufactured by Hynix Semiconductor. It is designed for applications that demand high memory bandwidth and capacity. This chip is organized as 128M x 8, indicating 128 million memory locations each storing 8 bits of data. DDR2 SDRAM provides improvements over DDR SDRAM, offering faster data transfer rates at similar clock speeds.

Applications

• Graphics Cards: Used to store textures, frame buffers, and other data required for real-time rendering.
• Gaming Consoles: Provides high-speed memory for game data, AI processing, and graphics.
• High-Definition Televisions (HDTVs): Supports video processing, buffering, and display functions.
• Set-Top Boxes: Manages data for decoding and displaying multimedia content from various sources.
• Networking Equipment: Used in routers and switches for storing routing tables and packet data.
• Industrial Control Systems: Provides memory for data acquisition, processing, and control functions.

Features

• 1Gb Capacity: Provides ample memory space for a wide range of applications.
• DDR2 Interface: Enables high data transfer rates compared to DDR SDRAM.
• 128M x 8 Organization: Provides a specific memory configuration for optimized access.
• Operating Frequency up to 667MHz: Supports fast data access and processing.
• Double Data Rate: Transfers data on both rising and falling edges of the clock signal.
• On-Chip DLL (Delay-Locked Loop): Ensures precise timing and synchronization.
• Write Latency of 3, 4, or 5 Clock Cycles: Offers flexible timing configurations to optimize performance.
• Power-Saving Features: Minimizes power consumption during idle and standby modes.
• Lead-Free Packaging: Complies with environmental regulations.

Benefits

• Improved System Performance: High memory bandwidth and fast access times enhance overall system responsiveness.
• Enhanced Graphics Capabilities: Supports complex textures and rendering effects for improved visual quality.
• Smoother Video Playback: High data transfer rates ensure seamless decoding and display of high-resolution video.
• Reduced Power Consumption: Extends battery life in portable devices and lowers overall energy costs.
• Increased Reliability: Robust design and manufacturing ensure stable operation under various conditions.
• Simplified System Design: Standard DDR2 interface facilitates easy integration with other system components.

Additional Details

The H5PS1G83EFR-S6I-C typically operates at a voltage of 1.8V. The S6I designation indicates a specific speed grade and temperature range. The C at the end likely signifies compliance with certain environmental standards or customer-specific requirements. The device is typically packaged in a FBGA (Fine-Pitch Ball Grid Array) for surface mount assembly. Detailed timing parameters, electrical characteristics, and package dimensions are available in the product datasheet. It is compliant with JEDEC standards for DDR2 SDRAM.
