Same model may have multiple batches, images only for reference.
SS561AT Real Image
Same model may have multiple batches, images only for reference.

SS561AT

Part No SS561AT
Manufacturer Honeywell
Catalog Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH LATCH SOT89B
Datasheet
SS561AT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Honeywell Sensing and Productivity Solutions
Packaging Reel - TR
Status Active
Purpose Latch
Technology Hall Effect
Polarization South Pole
Sensing Range 8.5mT Trip, -8.5mT Release
Testing Conditions 25°C
Supply Voltage - Operating 3.8 V to 30 V
Current - Supply (Max) 10mA
Current - Output (Max) 50mA
Output Type Open Collector
Features Temperature Compensated
Temperature Range - Operating -40°C to 150°C (TA)
Case / Package SOT-89B
Win Source Part Number 030857-SS561AT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SS561AT CAD Model

Description

This Honeywell Sensing and Productivity Solutions sensor is a high-quality product that is designed to meet the needs of various electronic applications.

  • Feature: Temperature Compensation
  • Technology: Hall Effect
  • Output Type: Open Collector
  • Polarization: South Pole
The product is ideal for use in electronic devices that require a reliable and robust sensor.
