Same model may have multiple batches, images only for reference.
FH35C-9S-0.3SHW(50) Real Image
Same model may have multiple batches, images only for reference.

FH35C-9S-0.3SHW(50)

Part No FH35C-9S-0.3SHW(50)
Manufacturer Hirose Electric Co Ltd
Catalog FFC, FPC (FlatFlexible) Connectors
Description CONN FPC 9POS 0.30MM R/A / 9 Position FPC Connector Contacts, Top and Bottom 0.012" (0.30mm) Surface Mount, Right Angle
Datasheet
FH35C-9S-0.3SHW(50) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>FFC, FPC (Flat Flexible) Connectors>FFC, FPC (Flat Flexible) Connector Assemblies
Manufacturer Hirose Electric Co Ltd
Packaging Reel - TR
Flat Flex Type FPC
Mounting Surface Mount, Right Angle
Connector/Contact Type Contacts, Top and Bottom
Number of Positions 9
Pitch 0.012" (0.30mm)
Termination Solder
FFC, FCB Thickness 0.20mm
Height Above Board 0.035" (0.88mm)
Locking Feature Flip Lock, Backlock
Cable End Type Tapered
Contact Material Phosphor Bronze
Contact Finish Gold
Housing Material Liquid Crystal Polymer (LCP)
Actuator Material Polyamide (PA), Nylon
Voltage Rating 30V
Temperature Range - Operating -55°C ~ 85°C
Material Flammability Rating UL94 V-0
Current Rating (Amps) 0.2A
Contact Finish Thickness 11.8µin (0.30µm)
Housing Color Gray
Actuator Color Black
Mating Cycles 10
Base Product Number FH35C
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4051
Other Part Number 580-2910-5-50
Standard Package 5,000
Win Source Part Number 1333388-FH35C-9S-0.3SHW(50)
Ultra Librarian 3D Model Ultra Librarian FH35C-9S-0.3SHW(50) CAD Model

Description

The Hirose Electric Co Ltd 1333388-FH35C-9S-0.3SHW(50) is a flat flexible connector assembly with a pitch of 0.012" (0.30mm) and 9 positions.

  • Mounting: Surface Mountable
  • Mounting Feature: Right Angle
  • Termination: Solder
  • Contact Finish: Gold
  • Voltage Rating: 30V
  • Current Rating: 0.2A
  • Height Above Board: 0.035" (0.88mm)
  • Mated Stacking Height: 4mm
  • RoHS Compliant: Yes
  • Standard Package: 5,000
  • Commonly Used In: FFC and FPC (Flat Flexible) Connector Assemblies Applications
