DF49-20S-0.4H(51)

Name: DF49-20S-0.4H(51)
Brand: Hirose Electric Co Ltd
SKU: 800628
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	DF49-20S-0.4H(51)
Manufacturer	Hirose Electric Co Ltd
Catalog	Rectangular Connectors
Description	CONN RCPT 20P 0.016 GOLD SMD R/A
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Hirose Electric Co Ltd
Packaging	Reel
Connector Type	Receptacle
Contact Type	Center Strip Contact
Style	Board to Cable/Wire
Number of Positions	20
Number of Positions Loaded	All
Pitch - Mating	0.016" (0.40mm)
Number of Rows	1
Mounting Style	Surface Mount, Right Angle
Termination	Solder
Fastening Type	Detent Lock
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	3.90μin (0.099μm)
Insulation Color	Black
Insulation Height	0.028"
Temperature Range - Operating	-35°C ~ 85°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Gold
Features	Solder Retention
Current Rating (Amps)	0.45A
Voltage Rating	30VAC
Insulation Material	Liquid Crystal Polymer (LCP), Halogen Free
Contact Material	Phosphor Bronze
Contact Finish Thickness - Post	1.97μin (0.050μm)
Manufacturer Pack Quantity	7,000
MSL Level	1 (Unlimited)
Popularity	High
Supply and Demand Status	Sufficient
Win Source Part Number	800628-DF49-20S-0.4H(51)
Ultra Librarian 3D Model	Ultra Librarian DF49-20S-0.4H(51) CAD Model

Alternative Products

Description

The DF49 series from Hirose Electric Co Ltd is a board to cable/wire style connector.

Connector Type: Receptacle
Solder Retention: Yes
Positions: 20
Mounting Type: Surface Mount, Right Angle
Contact Finish (Mating): Gold
Contact Finish Thickness (Mating): 3.90μin (0.099μm)
Contact Finish (Post): 1.97μin (0.050μm)
Voltage Rating: 30VAC
Current Rating: 0.45A
Insulation Material: Liquid Crystal Polymer (LCP)
