The DF11C-8DP-2V(57) is a 8-position, double-row crimp style connector from the DF11 series manufactured by Hirose Electric Co Ltd. These connectors provide a reliable and compact solution for board-to-wire connections.

Applications

• Factory automation equipment
• Robotics
• Medical devices
• Testing and measurement equipment
• Telecommunications equipment

Features

• Compact Design: Space-saving design for high-density mounting.
• Double-Row Configuration: Provides increased contact density.
• Crimp Termination: Offers secure and reliable wire termination.
• Polarization Feature: Prevents mismating.
• RoHS Compliant: Environmentally friendly, meeting RoHS standards.
• 2mm Pitch: Standard 2mm pitch allows for easy integration.

Benefits

• Reliable Connection: Ensures a stable and secure electrical connection, minimizing signal loss and downtime.
• Space Saving: Compact design optimizes board space utilization.
• Easy Termination: Crimp termination allows for quick and efficient assembly.
• Durable: Robust construction ensures long-term reliability in demanding environments.
• Versatile: Suitable for a wide range of applications.

Specifications

The DF11C-8DP-2V(57) connector has a current rating of 2A AC/DC and a voltage rating of 250V AC/DC. It has an insulation resistance of 1000 MΩ minimum and a contact resistance of 20 mΩ maximum. The operating temperature range is -55°C to +85°C. It's made of a UL94V-0 flame-retardant material, ensuring safety and reliability. The mating part is DF11 series.
