The M22-2522005 is a 40-position header, cuttable, male pin connector that is loaded with all positions.

• Positions: 40
• Connector Type: Header
• Features: Cuttable, Male Pin, Loaded
• Rows: 2
• Pitch-Mating: 0.079 inches (2.00mm)
• Connector Finish: Gold
• Contact Material: Phosphor Bronze
• Insulation Material: Polyamide (PA6T), Nylon 6T
• Insulation Color: Black
• Mounting: Through-Hole
• Shrouded: Unshrouded
• Temperature Range: -40°C to 105°C
• Current Rating: 1A per contact
• Connector Style: Board-to-Board
• Contact Shape: Square
• Overall Contact Length: 0.287 inches (7.30mm)
• Contact Length (Mating): 0.138 inches (3.50mm)
• Contact Length (Post): 0.091 inches (2.30mm)
• Standard Package: 100
