M20-9960645 Real Image
Same model may have multiple batches, images only for reference.

M20-9960645

Part No M20-9960645
Manufacturer Harwin Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER R/A 6POS 2.54MM / Connector Header Through Hole, Right Angle 6 position 0.100" (2.54mm)
Datasheet
M20-9960645 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Harwin Inc.
Series M20
Package Bulk
Connector Type Header, Cuttable
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 6
Number of Rows 1
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.240" (6.10mm)
Contact Length - Post 0.118" (3.00mm)
Insulation Height 0.100" (2.54mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Material Brass
Insulation Material Polyamide (PA6T), Nylon 6T
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A per Contact
Base Product Number M20-996
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names M209960645,952-2247
Standard Package 1,000
Win Source Part Number 1073433-M20-9960645
Ultra Librarian 3D Model Ultra Librarian M20-9960645 CAD Model

Description

The M20-9960645 is a header, cuttable connector manufactured by Harwin Inc.

  • Category: Rectangular Connectors - Headers, Male Pins
  • Series: M20
  • Number of Positions: 6
  • Connector Type: Header, Cuttable
  • Contact Type: Male Pin
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Package: Bulk
  • Insulation Material: Polyamide (PA6T), Nylon 6T
  • Pitch - Mating: 0.100" (2.54mm)
  • Contact Finish - Mating: Gold
  • Temperature Range - Operating: -40°C ~ 105°C
  • Current Rating (Amps): 3A per Contact
  • Popularity: Low
