Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Type Laminated Core
Voltage - Primary 120V
Voltage - Secondary (Full Load) 10V
Current - Output (Max) 500mA
Primary Winding(s) Single
Secondary Winding(s) Single
Center Tap No
Power - Max 5VA
Mounting Type Chassis Mount
Termination Style Wire Leads, Quick Connect
Size / Dimension 59.18mm L x 56.39mm W
Height - Seated (Max) 50.29mm
Weight 0.93 lb (421.84 g)
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1546142-BA2DA
Ultra Librarian 3D Model Ultra Librarian BA2DA CAD Model
