Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 800V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Maximum) at If 1.1V at 8A
Current - Reverse Leakage at Vr 5μA at 800V
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package 4-SIP, GBU
Supplier Device Package GBU
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Win Source Part Number 1177046-GBU8K
Manufacturer Homepage www.panjit.com.tw
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian GBU8K CAD Model

Description

The GBU8K diode is a product of GeneSiC Semiconductor.

  • Type: This single-phase diode has a current rating of 8A and a peak reverse voltage rating of 800V.
  • Application: The GBU8K diode is suitable for use in power management applications in a temperature range of -55°C to 150°C.
  • Package: The diode is packaged in a 4-SIP, GBU package and is available in a bulk package containing 500 units.
  • ECCN: The diode has an ECCN of EAR99 and an MSL level of 1 (Unlimited).
