FT232HL-REEL - USB to Serial/Parallel Interface IC

The FT232HL-REEL is a versatile USB to serial/parallel interface converter chip from FTDI, Future Technology Devices International Ltd. This innovative component is designed to make it simple for devices with legacy serial or parallel interfaces to connect to modern USB ports. It is perfect for a wide range of applications, including industrial controls, instrumentation, and communications systems.

Key Features:

• Single Chip USB to Serial/Parallel - The FT232HL integrates all the necessary components to facilitate serial and parallel data transfer over USB in a single chip, making it an efficient solution for system design.
• High-Speed USB 2.0 - With support for USB 2.0 Hi-Speed (480 Mb/s), the FT232HL ensures fast and reliable data transfer between the connected device and the host computer.
• Multipurpose UART/FIFO IC - The device features a multi-protocol synchronous serial engine (MPSSE) to simplify synchronous serial protocol (USB to JTAG, I2C, SPI, or bit-bang) design.
• Flexible Signal Options - It offers a variety of serial interface options including RS232, RS422, RS485, and others, providing great versatility for interfacing with different systems.
• Integrated Clock Circuit - The onboard clock generator eliminates the need for external clocking hardware, reducing BOM costs and simplifying PCB layout.
• Adjustable I/O Voltage - The I/O pin voltage can be adjusted from 1.8V to 5V to match the voltage levels of the target system.
• EEPROM Programmability - The device includes an internal EEPROM that can be programmed over USB, allowing for the customization of device descriptors and configuration settings.

Package and Supply

The FT232HL-REEL comes in a compact QFN-48 package and is supplied in tape and reel form, facilitating efficient pick and place manufacturing processes. It operates over a -40°C to +85°C temperature range, making it suitable for harsh environment applications.

Manufacturer Support

FTDI provides extensive technical support for the FT232HL-REEL, including datasheets, application notes, and reference designs, ensuring that developers can integrate the chip into their designs with confidence.
