NC7WZ14L6X Real Image NC7WZ14L6X real image3921 NC7WZ14L6X real image3922
Same model may have multiple batches, images only for reference.
NC7WZ14L6X Real Image NC7WZ14L6X real image3921 NC7WZ14L6X real image3922
NC7WZ14L6X Real Image NC7WZ14L6X real image3921 NC7WZ14L6X real image3922
Same model may have multiple batches, images only for reference.

NC7WZ14L6X

Part No NC7WZ14L6X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC INVERTER UHS DUAL SCHM 6MPAK
Datasheet
NC7WZ14L6X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 2
Number of Inputs 2
Features Schmitt Trigger
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 32mA, 32mA
Logic Level - Low 0.2 V to 1.2 V
Logic Level - High 1.4 V to 3.6 V
Max Propagation Delay @ V, Max CL 4.9ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 6-MicroPak
Dimension 6-UFDFN
Win Source Part Number 024874-NC7WZ14L6X
Popularity Medium
Supply and Demand Status Balance
Quantity per package 5k pcs
Ultra Librarian 3D Model Ultra Librarian NC7WZ14L6X CAD Model

Description

The Fairchild/ON Semiconductor electronic component with Win Source Part Number 024874-NC7WZ14L6X is an active product with a medium popularity.

  • Feature: Schmitt trigger
  • Circuits: 2
  • Logic Type: Inverter
  • Mounting Style: SMD (SMT)
  • Maximum Propagation Delay: 4.9ns @ 5V, 50pF
  • Current-Quiescent (Max): 1μA
  • Logic Level (Low): 0.2 V to 1.2 V
  • Logic Level (High): 1.4 V to 3.6 V
  • Supply Voltage: 1.65 V to 5.5 V
  • Package: 6-MicroPak (6-UFDFN)
  • Quantity: 5k pcs
